SPQJ型切片机技术参数
Technical Parameter of core slicing machine
切片机适用于地质、冶金、建材、煤炭、石油等工业实验室切取矿样及其他材料如玻璃、陶瓷、玉石、石英、金属试样切片。本产品由原地矿部唯一指定企业生产行业标准。
It serves to slice mineral sample in industrial laboratory of geology, metallurgy, building materials, coal and petroleum and so on. It also serves to slice other materials, such as glass, ceramics, jade, quartz and metal
切片机技术参数 Core slicing machine
| 型号规格Model |
单位Uite |
SPQJ-200台式 |
SPQJ-300 |
SPQJ - 400 |
| 金刚石刀片尺寸 Diamond blade sinze |
mm |
Φ200 |
Φ300 |
Φ400 |
| 刀片线速度 Blade linear speed |
m/s |
29 |
20-40 |
20 |
| 切割尺寸 Slicing dimension |
mm |
Φ15-Φ45
35×40 |
****60×70 |
100×100 |
| 功率 Power |
kw/V |
0.55/380 |
（0.8/1.1）/380 |
1.1/380 |
| 外形尺寸 Overall dimensions |
mm |
720×515×415 |
825×800×1105 |
865×560×1010 |
| 质量 Weight |
kg |
95 |
190 |
110 |
| |
