GZG型惯性振动给料机 Vibratory
feeder for motor
GZG型自同步惯性振动给料机广泛用于矿山、冶金、煤炭、建材、轻工、化工、电力、粮食等各行业，用以把块状、颗粒状及粉状物料从储料仓或漏斗中均匀连续或定量地给到受料装置中去。例如对破碎、选煤、筛分、运输、包装机械等给料、配料等。GZG系列给料机为普通槽型，用于无特殊要求的物料给料。
GZG vibratory feeder for motor are widely used in different
industries such as mining, metallurgy, coal, building material, light industry,
chemical, power and grain. They convey a given amount of block material,
granule material and powdery material from the storage silo or hopper to the
material receiving device in an even and uninterrupted way. For example, they
feed or distribute materials for crushing, coal preparing, screening,
transporting, and packaging machines. GZG series feeders adopt ordinary type of
chutes which are used for the feeding of materials for which there is no
special requirements.
| 型号规格 Model |
槽体尺寸 |
生产率 capacity |
给料粒度 Feed size |
振动力 |
功率 Power |
重量 Weight |
| 0°-10° |
| mm |
t/h |
mm |
kN |
kw |
t |
| GZG403 |
400×1000×200 |
30-40 |
100 |
2×5 |
2×0.25 |
0.17 |
| GZG503 |
500×1000×200 |
60-85 |
150 |
2×5 |
2×0.25 |
0.21 |
| GZG633 |
630×1250×250 |
110-150 |
200 |
2×10 |
2×0.5 |
0.34 |
| GZG703 |
700×1020×250 |
120-170 |
200 |
2×10 |
2×0.5 |
0.36 |
| GZG803 |
800×1500×250 |
160-230 |
250 |
2×16 |
2×0.75 |
0.57 |
| GZG903 |
900×1483×250 |
180-250 |
250 |
2×16 |
2×0.75 |
0.61 |
| GZG1003 |
1000×1750×250 |
270-380 |
300 |
2×20 |
2×1.1 |
0.76 |
| GZG1103 |
1100×1673×250 |
300-420 |
350 |
2×20 |
2×1.1 |
0.82 |
| GZG1253 |
1250×2000×315 |
460-650 |
350 |
2×32 |
2×1.5 |
1.07 |
| GZG1303 |
1300×2010×300 |
480-670 |
500 |
2×32 |
2×1.5 |
1.12 |
| GZG1503 |
1500×2250×300 |
720-1000 |
500 |
2×50 |
2×2.25 |
1.47 |
| GZG1603 |
1600×2500×315 |
770-1100 |
500 |
2×50 |
2×2.25 |
1.56 |
| GZG1803 |
1800×2325×375 |
900-1200 |
500 |
2×50 |
2×2.25 |
2.34 |
| GZG2003 |
2000×3000×400 |
1000-1400 |
500 |
2×50 |
2×2.25 |
2.62 |
| GZG705 |
700×1029×250 |
130-180 |
200 |
2×10 |
2×0.7 |
0.38 |
| GZG805 |
800×1500×250 |
170-250 |
250 |
2×10 |
2×0.7 |
0.48 |
| GZG905 |
900×1438×250 |
200-270 |
250 |
2×10 |
2×0.7 |
0.53 |
| GZG1005 |
1000×1750×250 |
290-410 |
300 |
2×20 |
2×1.52 |
0.62 |
| GZG1105 |
1100×1673×250 |
320-450 |
300 |
2×20 |
2×1.52 |
0.67 |
| GZG1255 |
1250×2000×315 |
500-700 |
250 |
2×20 |
2×1.52 |
0.89 |
| GZG1305 |
1300×2040×300 |
620-720 |
330 |
2×30 |
2×2.2 |
1.15 |
| GZG1505 |
1500×2250×300 |
780-1080 |
500 |
2×36 |
2×2.2 |
1.31 |
| GZG1605 |
1600×2500×315 |
330-1190 |
500 |
2×36 |
2×2.2 |
1.39 |
| GZG1805 |
1800×2325×375 |
970-1320 |
500 |
2×50 |
2×3.2 |
2.26 |
| GZG1256 |
1250×2000×315 |
500-700 |
350 |
2×30 |
2×2.2 |
1.18 |
| GZG1306 |
1300×2040×300 |
520-730 |
350 |
2×30 |
2×2.2 |
1.22 |
| GZG1506 |
1500×2250×300 |
780-1080 |
500 |
2×36 |
2×2.2 |
1.55 |
| GZG1606 |
1600×2500×315 |
830-1190 |
500 |
2×36 |
2×2.2 |
1.6 |
| GZG1806 |
1800×2325×375 |
970-1300 |
500 |
2×75 |
2×5.5 |
3 |
| GZG2006 |
2000×3000×400 |
1300-1800 |
500 |
2×75 |
2×5.5 |
3.3 |
| |
