GX型高效中心传动浓缩机 High-effiency thickener series
| 型号 规格 Model |
浓密池尺寸 Dia. of the tank |
耙子转速 Speed |
提耙高度 Lifting height |
处理能力 Capacity |
功率Power |
质量 Weight |
| m |
r/min |
mm |
t/h |
kw |
t |
| GX2.5 |
Φ2.5×1.73 |
1.68 |
200 |
≤1 |
0.75 |
4 |
| GX3.6 |
Φ3.6×1.98 |
1.10 |
200 |
≤1.2 |
0.75 |
5 |
| GX5.18 |
Φ5.18×2.38 |
0.80 |
300 |
≤3.75 |
1.5 |
10 |
| GX6 |
Φ6×2.96 |
0.30 |
300 |
≤4 |
2.2 |
10.5 |
| GX7 |
Φ7×3 |
0.30 |
300 |
≤7.3 |
2.2 |
12.2 |
| GX8 |
Φ8×3.32 |
0.25 |
300 |
≤8 |
2.2 |
13.8 |
| GX9 |
Φ9×3 |
0.47 |
400 |
≤8.75 |
3 |
14.6 |
| GX12 |
Φ12×3.6 |
0.30 |
400 |
≤15 |
4 |
16 |
| GX15 |
Φ15×4 |
0.20 |
400 |
≤24 |
4/2.2 |
19 |
| GX18 |
Φ18×4.4 |
0.13 |
500 |
≤40 |
5.5/2.2 |
21 |
| GX20 |
Φ20 |
0.145 |
400 |
≤45 |
5.5/2.2 |
22 |
| GX21 |
Φ21×4.4 |
0.10 |
500 |
≤60 |
5.5/2.2 |
24 |
| GX24 |
Φ24×4.4 |
0.09 |
500 |
≤80 |
2×2.2/4 |
26 |
| GX30 |
Φ30 |
0.069 |
600 |
≤96 |
2×2.2/4 |
29 |
| GNZ2 |
Φ2×1.8 |
1.17 |
160 |
＜0.9 |
1.1 |
2.23 |
| GNZ3 |
Φ3.6×1.7 |
1.10 |
200 |
＜1 |
1.5/0.75 |
3.17 |
| GNZ5 |
Φ5.18×2.13 |
0.80 |
300 |
＜3.75 |
4/0.75 |
3.68 |
| GNZ9 |
Φ9×2.8 |
0.427 |
300 |
＜8.75 |
3/2.2 |
14.6 |
| GNZ12 |
Φ12×3.6 |
0.35 |
500 |
＜15 |
3/2.2 |
16 |
| GNZ15 |
Φ15×3.8 |
0.35 |
500 |
＜24 |
4/2.2 |
19 |
| GNZ18 |
Φ18 |
0.193 |
500 |
≤40 |
5.5/2.2 |
21 |
| GNZ20 |
Φ20 |
0.145 |
600 |
≤45 |
5.5/2.2 |
22 |
| GNZ24 |
Φ24 |
0.085 |
600 |
≤80 |
2×2.2/4 |
26 |
| GNZ30 |
Φ30 |
0.069 |
600 |
≤96 |
2×2.2/4 |
29 |
| |
