CK型高效搅拌槽 High efficiency agitation tank

国家行业标准 JB/T9034

CK高效搅拌槽是一种新型浆体搅拌设备，具有90年代国际先进水平。

CK high efficiency agitation tank is a kind of new slurry agitation equipment which enjoys the advanced world level in the 90s.

矿浆呈"ω"型和圆周对流运动(专利)，流体上下周向流动，呈剪切对流循环 ，料浆弥散均匀。具有能耗低、弥散均匀、搅拌强烈、搅拌轮使用寿命长、固相不沉槽等特点。

The slurry takes the shape of “W” and makes circular convective motion (patent). The fluid flows up and down circumferentially and goes through shearing convective cycling. The slurry is evenly dispersed. It has characteristics such as low energy consumption, violent agitation, long service life of stirring vane and no sediment in tank of solid phase.

系列搅拌槽节能明显，能耗较老式搅拌槽可降低20%～40%，油药用量可减少20%左右，在系统停车后不需卸矿就可直接带矿启动，是取代常规搅拌槽、浸出槽的理想设备。可广泛应用于金属和非金属矿选矿、黄金浸出、湿法冶炼及某些轻化工原料生产部门。取得了良好的经济技术效益和社会效益。

This series of agitation tank is very energy-saving. Compared with old style agitation tanks, such ones can reduce 20% to 40% of energy, around 20% of medicament. They can directly drive the startup when ores are not unloaded after the system is shut down, hence ideal substitute for conventional agitation tanks and leaching tanks. Such agitation tanks are widely used in metallic and nonmetallic ore dressing, gold leaching, wet method smelting and some light chemical raw material production departments, which created great economic benefits and social benefits.

CK高效搅拌槽的结构及工作原理。下掠式搅拌轮的旋转，使矿浆在导流整流装置的作用下，按"W"形流迹上下剧烈循环。

Structure and Working Principle: The rotation of sweeping down agitation vanes causes violent up-and-down circulation of slurry according to “W” shape flow mark under the action of flow guiding and rectifying device.

1.搅拌强烈均匀，固相不离析、不沉槽；

1. The agitation is violent and even. Solid phase does not separate or sink into the tank.

2.节能降耗-能耗及油药用量较常规搅拌槽分别减少20%～40%

2. Such agitation tank saves energy and reduces consumption. Compared with conventional agitation tank, such agitation tank uses 20%～40% less of energy and medicament.

3.叶轮、导流装置寿命长-是常规搅拌装置使用寿命的十倍；

3. The vanes and flow guiding devices enjoys long service life, which is 10 times as long as that of conventional agitation devices.

4.操作简便、利用率高,系统停车后槽内无需卸矿即可直接启动。

4. It is easy for operation and enjoys high utilization ratio. After the shutdown of system, ores do not need to be unloaded from the tank before it is directly started.
