XY-1型钻机 Core drlling rig

XY-1型钻机是一种具有油压给进的轻便钻机,适用于普查勘探、地球物理勘探、道路及建筑勘探以及打爆破孔等钻进工程。不同的地层结构选用不同的合金、钢砂及钢粒等钻头可钻进2-9级的砂质粘土及基岩层等。本机额定钻孔深度100米，****开孔直经130mm经孔直经为75mm。

主要特点：

1、具有油压自动给进机构，提高钻进效率，减轻工人劳动强度。

2、采用球卡夹持机构代替卡盘，可实行不停钻倒杆，操作方便，安全可靠。

3、配有孔底压力计指示压力，便于掌握孔内情况。

4、手柄集中，操作简便。

5、结构紧凑，重量轻，适合于平原或山区工作。

6、重量轻、分解性强，便于搬迁。适合于平原或山区工作。

XY-1 drilling rig, as a portable rig with oil pressure feed function, is applicable for drilling works like prospecting and exploration, geophysical exploration, road & architectural exploration and blast hole drilling etc. Different alloy, steel sand and particle drills can be used for different stratum structures (e.g. levels 2-9 sandy clay and bedrock). The rated drilling depth of this rig is 100m; the minimum hole opening diameter is 130mm; the hole diameter is 75mm.

Key Features:

1. Auto oil pressure feed mechanism is provided to improve drilling efficiency and thus reduce labor intensity.

2. The easy-to-operate, reliable and safe ball-block holing mechanism that is used to replace the chuck can realize rod placement during drilling.

3. Hole-bottom pressure gauge is provided to indicate the pressure to facilitate the understanding of situation inside the hole.

4. Handles are concentrated for convenient operation.

5. Compact in structure, light in weight, applicable to works in plain and mountain areas.

6. Light in weight, high decomposability, portable, applicable to works in plain and mountain areas.
