试验室UX型电子托盘天平技术参数
Technical Parameters of Laboratory E-tray balance
响应性提高：只需0.7秒完成计测（-S型）
Improved responsiveness: calculation and measurement is completed within 0.7s (model –S)
耐冲击性提高：耐冲击的耐久性设计
Improved resistance to impact: durability design that is resistant to impact
温度特性提高：可进行随时间变化极少的计测，采用机内时钟功能，数据注入日期、时刻。内置“直通视窗”功能，与计算机连接，只需1根电缆线即可。附在计量时可了解目标的模拟显示。也可进行比重测定。与比重测定器具（选购件）配套可作比重计使用。可选择个数、%、克拉等丰富多样的计量方式。可用电池（选购件）驱动。
Improved temperature property: measurement that is almost not subject to time; internal clock function; data assigned to date and time. The built-in “Straightway Window” function makes it possible to connect with computer with one piece of cable. The analog display of object is available during the measurement. Specific gravity determination is also available. This equipment can be used as densimeter when being used with specific gravity measurement apparatus (option). Various measurement forms (number, %, carat etc.) are available. Battery-operated mode (option) is available.
型号规格
Model |
标准量程型 Standard Range Type |
| UX420S |
UX820S |
UX4200S |
UX8200S |
| （321-62350-04） |
（321-62350-05） |
（321-62350-09） |
（321-62350-10） |
称量能力
Weighing capacity |
420g |
820g |
4200g |
8200g |
最小显示值
Minimum displayed value |
0.01g |
0.01g |
0.1g |
0.1g |
称量盘尺寸(mm)
Weighing plate size |
约108×105 |
约108×105 |
约170×180 |
约170×180 |
| 耗电量 Consurmption |
12VA以下 |
型号规格
Model |
宽量程型 Wide-range type |
| UX220H |
UX420H |
UX620H |
UX2200H |
UX4200H |
UX6200H |
| (321-62350-01) |
(321-62350-02) |
(321-62350-03) |
(321-62350-06) |
(321-62350-07) |
(321-62350-08) |
称量能力
Weighing capacity |
220g |
420g |
620g |
2200g |
4200g |
6200g |
最小显示值
Minimum displayed value |
0.001g |
0.001g |
0.001g |
0.01g |
0.01g |
0.01g |
称量盘尺寸(mm)
Weighing plate size |
约108×105 |
约108×105 |
约108×105 |
约170×180 |
约170×180 |
约170×180 |
| 耗电量 Consurmption |
12VA以下 |
|
